TVOC 2 Continuous VOC Gas Detector
This robust fixed continuous VOC gas detector has a selectable detection range of 0 – 10 ppm, 0 – 100 ppm or 0 – 1000 ppm and is ideal for use in manufacturing and process industries where VOCs are typically present. With a 4-20 mA analogue output, the fixed continuous VOC gas detector can be simply integrated into a Distributed Control System (DCS) to provide warnings and enable control of high VOC levels in your working environment.
Features
The TVOC 2 fixed continuous VOC gas detector has ATEX approvals that enable a 3 wire TVOC system to be used in Zone 2 hazardous areas without safety barriers, whilst its ATEX and IECEx approvals allow TVOC 2 to be used in Zone 1 hazardous areas with safety barriers.
Simple to install service and calibrate, TVOC 2 fixed continuous VOC gas detector requires no hot work permit and the PID sensor is accessible and changeable in a matter of seconds.
![](/admin/uploadpic/202203/20220323151001413.jpg)
Technical Specification
![IECEx certification](https://ionscience.com/wp-content/uploads/2021/06/IECEx-64x64-1-e1591631805638-2.png) ![ATEX certfication](https://ionscience.com/wp-content/uploads/2021/06/ATEX-64x64-1-e1591631823988-2.png)
Approvals:
- II 2G Ex ia IIC T4 Gb (-20 °C ≤ Ta ≤ +50 °C)
- II 3G Ex nA IIC T4 (-40 °C ≤ Ta ≤ +50 °C)
- Baseefa05ATEX0277X
- IECEx BAS 06.0057X
Ingress Protection:
- Designed to IP65 - Sensor ingress protection IP54
Power:5 – 28 VDC Max 130 mA
Output:
- 4-20 mA requires a 8-35 VDC power supply - For IS requirements 8-30 VDC power supply
Range:0 to 10 pp, 0 to 100, 0 to 1000 ppm (user selectable)
Sampling: Diffusion (can be pumped if required using an adaptor)
Display: 7 segment, 4 digit LCD, 4 colour LEDs
Response: Sensor – T90 < 5 secs
Accuracy:
0 to 100 ppm: ± 5 % calibration point 100 to 1000 ppm: ± 10 % at calibration points
Calibration:
Accessed via magnetic switch 100 ppm isobutylene via calibration kit accessory
Temperature:
- Operating: – 20 to 50 °C (- 4 to 122 °F) - Humidity: 0-95% RH (non-condensing)
Weight and Dimensions:
- Instrument: 1.4 kg (3.1 lb) Packed: 1.6 kg (3.5 lb) - Dimensions: 188 x 126 x 78 mm (7.4 x 4.9 x 3″)
4 – 20 mA Alarm Levels: Selectable 2 mA & 3.5 mA options
|
