SF6 AreaCheck P2

Fixed SF6 gas detector

This fixed SF₆ gas detector utilities relay output for immediate awareness of detected leaks and presents no cross sensitivity with any other gas or moisture in the air. The SF₆ gas detector has a built-in low flow alarm and self-diagnostic testing.

Features

The fixed SF₆ gas detector has serviceable components with a lifetime of up to 12 months. Measuring stations are maintenance-free, ensuring instrument downtime for the SF₆ gas detector is minimised.

Technical Specification

Detection Principle: SF₆: NIC

Range: 0 – 2000 ppm SF₆

Resolution: 500 ppm SF6 / 10 ppm

Mains Power: 100 – 240 VAC, 50/60 Hz

Power Consumption: 18 VA

Operating Temperature: – 5 to 45 °C

Storage Temperature: – 20 to 60 °C

Operating Humidity Range: 10 – 90 % non condensing

Max Load, Relay Output: 2.5 A / 230 VAC

Size: H 280 x B 165 x T 125 mm

Protection Class: IP52

Audible Alarms: > 75 dbA, 1m

Weight: 1.5 kg (w/o wall mounting bracket)

Fuse: T 1A (slow blow)
