TURBORECOVER™ RECOVERY MACHINE
OVERVIEW
TurboRecover™ for fast and effective refrigerant recovery.
The YELLOW JACKET® TurboRecover™ has all the features you need for fast and effective refrigerant recovery. The powerful twin-cylinder, oil-less compressor and 1.25 hp Brushless DC (BLDC) motor ensure fast recovery of every system. Lightweight design and included shoulder strap allow for easy transportation to any jobsite. The single control valve and status indicator LED make it the simplest recovery machine on the market!
Dual-gauge design allows for monitoring of the system and tank pressures simultaneously and integrated low-pressure switch automatically powers down the machine when the system reaches 10” of vacuum. Integrated purge circuit clears residual refrigerant from the machine, preventing cross-contamination when changing from one refrigerant to another. The reusable mesh particulate filter is integrated into the suction port and can be easily cleaned or replaced. TurboRecover™ includes all of these great features to make your job easy.
FEATURES:
- Fully automatic operation for fast recovery of Class III, IV and V refrigerants including R-410A and A2L refrigerants
- Powerful twin-cylinder, oil-less compressor and 1.25 hp Brushless DC (BLDC) motor ensures fast recovery
- Lightweight design and included shoulder strap allow for easy transportation
- Single valve control for simple operation and easy changeover from recover to purge
- Status indicator LED provides notification of machine faults and completed recovery
- Dual-gauge design allows for monitoring of the system and tank pressures simultaneously
- Low pressure switch provides automatic shut-off when unit reaches 10” of vacuum
- Integrated purge function clears residual refrigerant to prevent cross-contamination
- Reusable mesh particulate filter is integrated into the suction port and can be easily cleaned or replaced
- Controls and gauges inset for protection and angled for easy access and viewing
- Senses back pressure from tank and shuts off automatically at 517 psi for safety
- High air flow fan with a micro-channel condenser to keep the unit running cool
- 10’ Locking power cord(s) eliminate the need for extension cord
- Dual voltage: 110/240V
- Tested by UL to ARI 740-2016 and certified by Intertek to meet CSA C22.2 No. 120
- Ignition Proof design tested and approved to ANSI/ISA 12.12.01:2016 Ed.7
SPECIFICATIONS:
- Capabilities: Vapor, liquid, push/pull
- Refrigerants: All Class III, IV, and V, including R-410a and A2L refrigerants
- Compressor: Driven by 1.25 hp BLDC motor, twin cylinder, oil-less
- Power Source: 100-240VAC, 50/60Hz
- High-Pressure Shut-Off: 517 psi/35 bar – auto reset
- Operating Temperature: 32° to 120°F (0° to 49°C)
- Weight: 25.2 lbs (11.4 kg)
- Dimensions: 14.5”L x 9.5”W x 12”H (370mm x 240mm x 305mm)
|
